B.A. Eagle .61 1760mm GP/EP ARF

Black Horse B.A. Eagle .61 ARF – 1790 mm

Classic scale model for glow, petrol or electric power

The Black Horse B.A. Eagle is an elegant ARF aeroplane inspired by the British B.A. Eagle II from the 1930s. The model has a classic balsa and plywood construction and comes covered in Oracover.

The plane is fitted with flaps, which give better control at low speed and allow slower, more controlled landings. The model can be built with either an internal combustion engine or a powerful brushless electric set-up.

Features

• ARF scale model of the B.A. Eagle
• Balsa and plywood construction
• Factory-covered in Oracover
• Flaps for better low-speed and landing characteristics
• NACA wing profile
• Oleo landing gear included
• Can be built for glow, petrol or electric motor
• Suitable for realistic scale flying

Specifications

• Wingspan: 1790 mm
• Length: 1340 mm
• Weight: approx. 4 kg
• Wing area: 45.7 dm²
• Wing loading: 87.53 g/dm²
• Wing profile: NACA
• Spinner: 58 mm
• Servo size: 42 x 21 mm
• Radio: minimum 5 channels
• Number of servos: 7

Recommended power set-up

• 2-stroke glow engine: .61 class
• Petrol engine: approx. 15 cc
• Electric motor: Brushless outrunner, 1200-2200 W / approx. 650KV
• Recommended electric motor: RimFire .60 or equivalent
• ESC: approx. 80A
• Battery: 6S LiPo 4000-5000 mAh
• Receiver battery: 6V NiMH 1200-2000 mAh where relevant to the set-up
• Choose the propeller to suit the motor used

What you need

The model is supplied as an ARF and requires final assembly. As a minimum, you need to buy a suitable radio system with at least 5 channels, 7 servos, plus an engine or motor and the related equipment. For an electric set-up, you also need a brushless motor, ESC, 6S LiPo battery, compatible charger and a suitable propeller.
